The 152FIND-1 is a high efficiency, (95 dB 1watt / 1 meter) 15-inch woofer with linear frequency response characteristics and high power handling capability. The 152FIND-1 uses a lightweight carbon fiber loaded cone assembly along with a high excursion rubber surround. This combination greatly improves low-frequency response and provides great level of control over the moving cone at high excursion levels. We have designed a lightweight surround, using our own rubber compound. As the result, the SPL is not compromised and the woofer can be used in professional audio applications, where high amounts of low frequencies are required. Power Handling At the core of the 152FIND-1 is it’s voice coil technology featuring a composite Polyimide former material capable of withstanding peak temperatures in excess of 280C, well beyond the thermal requirements of modern professional audio systems. The 152FIND-1 cone is extensively treated to withstand harsh environments and high humidity. Metal parts in the speaker assembly are coated for extreme weatherization protection.
Specifications General Specs
Nominal Diameter: 15 inch
Rated Impedance: 8 Ohm
Power Handling
AES Power: 800 Watts
Program Power: 1600 Watts
Voice Coil
Diameter: 3 inch
Winding wire : CCAW
Former: Glass Fiber
Winding height: 19 mm
T/S Parameters
Resonant frequency: 37Hz
Re: 4.6ohm
Qes: 0,46
Qms: 10,2
Qts: 0,44
VAS: 119L
Sd: 804cm2
Mms: 140g
BL: 18.4
Le: 0,55
Sensivity: 95,62 dB
Design Details
Surround material: Rubber
Cone material: Paper
Spider: Nomex
Plate thickness: 10 mm
Peak to peak linear cone displacement: 14,5 mm
Overall diameter: 392 mm
Bolt circle diameter: 375 mm
Baffle cutout dia: 360 mm
Number of mounting holes: 8
Depth (flange to rear): 143 mm
Net weight: 9kg
